These Die-cast metal humbucker mounting rings feature an arched bottom to better fit the contours of a carved guitar top such as a Les Paul or ES-335 style body.

This ring is angled in height. It is typically positioned so that the side closest to bridge is taller than the side closest to the neck or fretboard.

Specifications:

• Angled bottom from 13/32 inch height to 31/64 inch height.
• Outer Dimensions: Length = 3-39/64 Width = 1-13/16
• Mounting Hole locations: 3-¼ inches apart on the length X 1-½ inches apart on the width
• Center-to-center distance between height adjustment holes: 78mm (3.07 in)

WD Music SKU: MRMH4CR

Note: This listing includes the mounting ring only. A variety of pickup mounting ring and height adjustment screws are available separately.

Professional installation is strongly recommended. Improper installation may result in damage to the product and/or instrument.
