Kluson KHBSN Harmonica Tuneomatic Bridge w. Studs and Inserts - Nickel

Kluson KHBSN Harmonica Tuneomatic Bridge w. Studs and Inserts - Nickel

Price
Regular price $165.90
Regular price Sale price $165.90
Save $-165.90
/

  • Available For Special Order Only

Special orders must be paid in advance and will ship when they become available. Due to the nature of this type of order, your purchase may require several weeks for shipment. Any estimated shipping date given is subject to change.

Terms

  • Invoice must be paid in full before the order is placed
  • These orders are excluded from promotions, including shipping discounts
  • Once placed, special orders cannot be altered, cancelled, or returned
  • May be subject to a special order processing fee



This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

This bridge, popularly referred to as the harmonica bridge is a direct replication of the original using all the same quality fabrication, dimensions and best of all, milled from steel billet to give you the tone you crave. A proper replacement for all those vintage Gibson® guitars with no modifications neccessary. Studs and inserts included.

Specifications:

  • Bridge Dimensions = 3.5 in. L X 1 in. W X 25/64 in. at center
  • E to E String Spacing = 52mm
  • String Pitch = 10.4mm
  • Radius = 12 inch
  • Material = Billet Steel w/ un-plated brass saddles
  • Stud thread = 8mm X 1.25 pitch
  • Spacing Center to Center = 2 7/8 in. (73mm)
  • Stud top diameter = 4.7mm
  • Stud base diameter = 9.5mm
  • Inserts included

Kluson SKU: KHBSN

Professional installation is strongly recommended. Improper installation may result in damage to the product and/or instrument.
